ATL-45/28 Small Plastic Lids Thermoforming Machine

（PET/HIPS/PVC）

The Machine (Forming Area 450×280mm) combines heating, forming,cutting and punching in one machine. It’s specially made for PET HIPS dome lids and coffee flat lids, small tray and clamshell production. If you have below requests on machine:

Small investment;
Low mold cost;
Small install dimension；
Wide usage;

Cost-effective Quick Start,Choose ATL-45/28

Small budget but want to explore new market fast?

ATL-45/28’s economical price allow you start to business soon.
Its small but cost-effective mold allow to start various products for new market and customers.
Compact size with 4.3m length, small space for shipping and installing cost.
Its 24h stable running speed in mass production for your market.

Small but various products, Choose ATL-45/28

Large machines incur high startup and mold-opening costs for small order?

ATL-45/28’s small but cost-effective mold allow to start various products for new market and customers.
Low power consumption to reduce electrical bills.
Machine’s 4 station working ways suits for multi-type products production.

Economical hole-punching machine, Choose ATL-45/28

Too high machine and mold cost of large 4 station machine make small-batch order production uneconomical.

ATL-45/28 integrate heating-forming-hole punching-cutting-stacking in one machine for wide production.
Without extra cost for hole punching on normal products, like coffee lids.
Greatly meet the small quantity but with hole-punching production request.

Lower Power Loss, Choose ATL-45/28.

Traditional ceramic heater consume excessive power and cause over heating of PET and HIPS products.

ATL-45/28 adopts heating plates replace traditional ceramic tiles, which fits closely to mold with fast heat transfer to cut heat loss；
Its power consumption lower to 7kw/h to save electricity bills.
Consistent evenly heating guarantees superior material transparency and complete product forming.

Specifications

Machine model	ATL-45/28
Forming area	450×280mm
Forming depth	45mm
Suitable material	PET/HIPS/PVC
Sheet thickness range	0.10-1mm
Knife length	3500mm
Sheet roller maxi weight	80kg
Production Speed	15-25cycles/min
Approximate power consumption	7kw/hr
Voltage	380v,3phase,50hz
Weight	2500kg
Dimension	4300x1120x2000mm

ATL-45/28 Support Material

Our ATL-45/28 machine can stably process PET, HIPS, PVC thermoforming sheets. You can clearly see what you’ll be able to produce after choosing our ATL-45/28 by below sample pictures.

PET（Polyethylene Terephthalate）

PET(APET/R-PET) features high transparency, good low-temperature resistance, non-toxic and odorless, safe for food contact, environmentally friendly and recyclable. It is suitable for packaging container for bakery pastries, fresh food, fruits, vegetables, cold drinks and other products.

HIPS（High Impact Polystyrene）

HIPS features good toughness, easy processing and low cost, and can be anti-static, suitable for structural support packaging such as electronics, hardware, toys liners and lids covers.

PVC（Polyvinyl Chloride）

PVC features good flexibility, easy forming, low cost and strong protection, suitable for blister and folding boxes for stationery, toys, hardware, cosmetics and other non-food products.

Video of one station thermoforming machine

This video shows the working process of a small 4 station thermoforming machine，which integrates heating, forming, hole punching，cutting and stacking in one machine, easy operation and stable production capacity.

Advantage

Servo System

Japan Yaskawa servos for smooth running with low noise.

Independent Loader

Independent loader driven by air cylinder for bigger rolls.

Heating Zone

Heating plates replace traditional ceramic tiles to reach closely to mold with fast heat transfer to cut heat loss；

Hole punching support

Air cylinder driven hole punching.

Save labor

Auto stacking and belt conveyor for products set up easily.

Top branded parts

Branded parts like Siemens,Schneider,Panasonic ensures long-term stable production.

Buyer Show

Thanks to its economical machine cost and multi-functional production capability, ATL-45/28 sells well across the Middle East, Africa, Southeast Asia and many other regions. Its stable performance has been verified through actual on-site production.
